Mold Design Diploma (Core/Cavity Extraction)
The demand for skilled Mold Design Engineers is rapidly increasing across plastic, injection molding, and die-casting industries.
Our Mold Design Diploma (Core/Cavity Extraction) program is designed for students and professionals who want to master parting line creation, parting surface development, and core–cavity extraction through a practical, industry-focused approach.
This course takes you from product analysis to complete mold core/cavity generation using professional CAD tools used in the real world.
Course Highlights
Complete Mold Design Diploma focused on Core & Cavity Extraction
Practical training using industry-standard CAD software
Learn the full workflow: Part → Parting Line → Parting Surface → Core & Cavity
Real product-based practice and assignments
Understanding of DFM (Design for Manufacturing) considerations
Guided final project to build a professional mold design portfolio
Interview preparation support for design-job roles
Who Should Enroll?
This course is ideal for:
Students from Mechanical, Production, Automobile, or Tool & Die Engineering
Fresh graduates planning to build a career in design engineering
CAD learners who want to specialize in mold design
Working professionals looking to upgrade skills or switch to the mold/tooling domain
🕒 Course Duration
Duration: 6 to 8 Months (Flexible Batch Options)
Mode: Classroom / Online / Hybrid
Training Hours: 200+ Hours including Projects & Assessments
Detailed Curriculum
| Module No. | Module Name | Topics Covered | Key Outcomes |
|---|---|---|---|
| 1 | Introduction to Injection Molding | Basics of Molding, Mold Types, Mold Components, Material Behavior | Strong understanding of mold design fundamentals |
| 2 | Product Study & Draft Analysis | Draft Analysis, Thickness Analysis, Identifying Undercuts, Part Orientation | Ability to evaluate any component for mold development |
| 3 | Parting Line & Parting Surface Design | Determining Parting Direction, Creating Parting Lines, Building Parting Surfaces | Skills to develop clean & accurate parting lines/surfaces |
| 4 | Core & Cavity Design Concepts | Core/Cavity Theory, Shrinkage, Allowances, Mold Block Basics | Understanding of industrial core–cavity design workflow |
| 5 | Core & Cavity Extraction (CAD Practical) | Split Feature, Mold Tools Workspace, Block Creation, Fixing Surface Errors | Ability to extract core & cavity using professional CAD tools |
| 6 | Mold Layout Overview | Runners, Gates, Sprue Basics, Ejection System Overview, Cooling Concepts | Knowledge of complete mold structure & functional elements |
| 7 | Design for Manufacturing & Mold Defects | DFM Guidelines, Common Defects (Flash, Sink, Warpage), Preventive Measures | Skills to design molds with fewer defects & higher manufacturability |
| 8 | Final Core–Cavity Project | Full Core & Cavity Extraction of a Real Product, Documentation | Hands-on portfolio project demonstrating complete mold workflow |
